NM350A is an active biamplified high performance system that takes the same shell of the NM250 but with a significant increase of power and components’ efficiency, getting a wider frequency response, a more accurate timbre and definition also thanks to the new 1” driver.
Compared to the NM250, we reached the goal to have a major sound pressure, distorsion reduction (that allows to even double the audio coverage distance) with smaller weight.
APPLICATIONS
- Small live session, even outdoor
- Pianobar or Dj-Set, eventually paired with the Earth112 subwoofer.
- Small and medium band for gigs or studio sessions
TECHNICAL SPECIFICATIONS
| SPECIFICATIONS | NM350A - 2-way active bi-amplified |
| Frequency response | 58 Hz - 20 Khz ± 2dB |
| Max SPL | 126 dB |
| Components LF | Custom designed 8" high efficiency wide excursion woofer (2" voice coil) |
| Components HF | Custom designed 1" compression driver (1" voice coil) constant directivity horn (90°H X 60°V). |
| Built- in power amplifier | 2 Mosfet, class AB, dedicated power units with 2 independent dynamic processors; ' start soft' circuit |
| Total Output Power | 350W (LF 300W + HF 50W) |
| Dimensions (WxHxD) | 250 x 425 x 230 mm |
| Weight | 8.6 Kg |
